Gigabyte B850 GAMING WIFI 6 – AM5 Motherboard with PCIe 5.0

About the Gigabyte B850 GAMING WIFI 6

The Gigabyte B850 GAMING WIFI 6 targets builders who want modern AMD features at a fair price. This AM5 motherboard works with Ryzen 9000, 8000, and 7000 series processors. At SGD 305, you get PCIe 5.0 storage capability, built-in WiFi 6, and DDR5 memory support. The B850 chipset sits between basic B650 and premium X870 options. Great for mid-range gaming builds or your first DIY PC project.

What This Gigabyte B850 GAMING WIFI 6 Does for You

This entry level motherboard for gaming brings PCIe 5.0 support on the primary M.2 slot (with Ryzen 7000/9000). Your Ryzen CPU gets fast storage speeds for loading modern games quickly. WiFi 6 and Bluetooth 5.3 eliminate the need for extra adapters. Three M.2 slots plus four SATA connectors give you plenty of storage expansion room. DDR5 support reaches 8200 MT/s when overclocked, keeping your RAM from bottlenecking performance. VRM cooling is designed to keep Ryzen CPUs stable with adequate case airflow during gaming sessions. Clean layout makes cable management straightforward for first-time builders.

Connectivity Options

The I/O panel covers your essential needs without extra fluff. DisplayPort and HDMI outputs work with Ryzen CPUs that have integrated graphics. Two USB 3.2 Gen 2 ports (red) deliver fast transfer speeds for external drives. USB Type-C port handles modern peripherals and accessories. Realtek Gigabit LAN provides stable wired connection for online gaming. WiFi 6 covers 2.4/5 GHz bands when you can't run ethernet cables. Realtek audio codec supports 7.1-channel surround sound for immersive gaming audio.

Perfect For

• Mid-range Ryzen 9000/7000 gaming builds that need reliable AM5 platform features without X870 pricing
• First-time builders wanting wireless connectivity and multiple storage slots without complicated setup
• Users upgrading from older AM4 platforms to DDR5 and PCIe 5.0 technology
• Streamers needing WiFi connectivity and space for capture card plus multiple drives

Why Buy from Mansa Computers

• 3-year Singapore warranty with CDL Trading Pte Ltd service support
• Fast WhatsApp inquiry response for compatibility questions
• Open 7 days a week for support
• Home delivery available across Singapore

Technical Specifications Summary

Chipset
AMD B850

CPU Socket
AM5 (Ryzen 9000/8000/7000)

Memory
4x DDR5, up to 256GB, 8200 MT/s OC

Storage
3x M.2 (1x PCIe 5.0), 4x SATA

Wireless
WiFi 6, Bluetooth 5.3

Rear I/O
2x USB 3.2 Gen 2, 1x Type-C, DP, HDMI

Form Factor
ATX (30.5cm x 24.4cm)

Warranty
3 years (CDL Trading Singapore)

The Gigabyte B850 GAMING WIFI6 brings X870-tier features at B850 pricing. Ready to build your Ryzen system with proper wireless connectivity and PCIe 5.0? We're here to answer questions.

CPU
AMD Socket AM5, support for:
AMD Ryzen™ 9000 Series Processors/
AMD Ryzen™ 8000 Series Processors/
AMD Ryzen™ 7000 Series Processors

Chipset
AMD B850

Memory
Support for DDR5 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C) / 6200(O.C) / 6000(O.C) / 5800(O.C) / 5600(O.C) / 5200 / 4800 / 4400 MT/s memory modules.
4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity)of system memory
Dual channel memory architecture
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules

Onboard Graphics
Integrated Graphics Processor with AMD Radeon™ Graphics support:
- 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz
- 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

Audio
Realtek® Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel

LAN
Realtek® GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)

Wireless Communication module
Realtek® Wi-Fi 6 RTL8851BE
- WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands
- BLUETOOTH 5.3
- Support for 11ax 80MHz wireless standard

Expansion Slots
1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode
AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
Chipset:
- 3 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1, PCIEX1_2, PCIEX1_3)

Storage Interface
1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:
AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs
AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:
AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs
1 x M.2 connector (M2C_SB), integrated in the Chipset, supporting Socket 3, M key, type 22110/2280 PCIe 4.0 x2 SSDs
4 x SATA 6Gb/s connectors
RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
RAID 0, RAID 1, and RAID 10 support for SATA storage devices

USB
CPU:
- 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 1 support
- 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
Chipset:
- 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header
- 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header)
- 4 x USB 2.0/1.1 ports on the back panel
Chipset+USB 2.0 Hub:
- 4 x USB 2.0/1.1 ports available through the internal USB headers

Internal I/O Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 4-pin ATX 12V power connector
1 x CPU fan header
1 x CPU fan/water cooling pump header
3 x system fan headers
1 x system fan/water cooling pump header
3 x addressable RGB Gen2 LED strip headers
1 x RGB LED strip header
3 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C® header, with USB 3.2 Gen 1 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only)
1 x reset jumper
1 x Clear CMOS jumper

Back Panel Connectors
1 x DisplayPort (Note)
1 x HDMI port (Note)
1 x Q-Flash Plus button
4 x USB 2.0/1.1 ports
1 x PS/2 keyboard/mouse port
2 x USB 3.2 Gen 2 Type-A ports (red)
1 x USB Type-C® port, with USB 3.2 Gen 1 support
1 x RJ-45 port
2 x USB 3.2 Gen 1 ports
2 x antenna connectors (2T2R)
3 x audio jacks

I/O Controller
iTE® I/O Controller Chip

H/W Monitoring
Voltage detection
Temperature detection
Fan speed detection
Water cooling flow rate detection
Fan fail warning
Fan speed control

BIOS
1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features
Support for GIGABYTE Control Center (GCC)
Support for Q-Flash
Support for Q-Flash Plus
Support for Smart Backup

Bundled Software
Norton® Internet Security (OEM version)
LAN bandwidth management software

Operating System
Support for Windows 11 64-bit
Support for Windows 10 64-bit

Form Factor
ATX Form Factor; 30.5cm x 24.4cm

3 YEARS WARRANTY

CDL Trading Pte Ltd
115A Commonwealth Dr #03-10, Singapore 149596
Contact: 6473 4733

Frequently Asked Questions About Gigabyte B850 GAMING WIFI 6

Does this Gigabyte B850 GAMING WIFI 6 support PCIe 5.0 graphics cards?

Yes, the primary PCIe x16 slot runs at PCIe 5.0 speeds with Ryzen 9000 or 7000 CPUs. It also includes a PCIe 5.0 M.2 slot for fast SSDs. Future-proofs your system for upcoming hardware.

Can I build a Ryzen 9 7900X system with this motherboard?

Absolutely. The B850 chipset handles Ryzen 9 7900X with good VRM thermal performance for gaming workloads. You get DDR5 support, PCIe 5.0 slots, and WiFi 6 connectivity at a reasonable price.

Will my DDR4 RAM work on this board?

No, all B850 motherboards only support DDR5 memory modules. You'll need to buy DDR5 RAM. This board supports speeds up to DDR5-8200 with overclocking for excellent performance.

What warranty coverage comes with this motherboard in Singapore?

You receive 3-year warranty through CDL Trading Pte Ltd, Gigabyte's authorized Singapore distributor. That's longer than typical 2-year coverage. Local service means no international shipping hassles.

What makes B850 different from X870 motherboards?

B850 includes PCIe 5.0, DDR5, and WiFi 6 like X870 but costs SGD 150-200 less. You sacrifice some USB ports and advanced overclocking features. Most gamers find B850 offers better value.
