Gigabyte B850M Aorus PRO WIFI7 Motherboard

Gigabyte B850M Aorus PRO WIFI7 Motherboard

Name: Gigabyte B850M Aorus PRO WIFI7 Motherboard
Brand: Mansa Computers
Price: 399.0 SGD
Availability: InStock

SKU: B850M A

STRONG ∙ FAST ∙ READY

You want strength. You want speed. You want readiness.

This board brings PCIe 5.0 with DDR5 up to 8600MT/s. Faster graphics. Higher memory clocks. Performance that lasts. It equips dual PCIe 5.0 M.2 slots plus SATA. More storage. Quicker load times. Reliability under pressure.

It connects with Wi-Fi 7 and 2.5Gb Ethernet. Stable wireless. Strong wired. No lag in the fight. This is not just a motherboard. This is your foundation to win.

Key Features

Chipset: AMD B850

Memory: 4× DIMM DDR5, up to 256GB, Supports DDR5 8600+ (OC) down to 4800 MT/s, Dual Channel, Non-ECC Unbuffered, Supports AMD EXPO™ & Intel XMP

Expansion Slots: 1× PCIe 5.0 x16 (Ryzen 9000/7000), 1× PCIe 4.0 x16 (x4, chipset)

Storage: 2× M.2 PCIe Gen5/Gen4 (CPU-based), 4× SATA 6Gb/s ports, NVMe RAID 0/1/5/10 (Ryzen 9000), SATA RAID 0/1/10

Form Factor: Micro-ATX

3 Years Warranty

DDR5 Memory

PCIe 5.0 Expansion

$399.00

Full Specifications

Model Name
B850M A PRO WIFI7

Brand
GIGABYTE

CPU Support
AMD Socket AM5 for Ryzen™ 9000 / 8000 / 7000 Series

Chipset
AMD B850

Memory
4× DIMM DDR5, up to 256GB
Supports DDR5 8600+ (OC) down to 4800 MT/s
Dual Channel, Non-ECC Unbuffered
Supports AMD EXPO™ & Intel XMP

Graphics
1× USB Type-C (DisplayPort 1.4, up to 4K@144Hz*)
1× HDMI 2.1 (up to 4K@60Hz)
1× Front HDMI 1.4 (1080p@30Hz)
Supports triple-display output
(*Up to 40Gbps bandwidth with Ryzen 8000 CPUs)

Expansion Slots
1× PCIe 5.0 x16 (Ryzen 9000/7000)
1× PCIe 4.0 x16 (x4, chipset)

Storage
2× M.2 PCIe Gen5/Gen4 (CPU-based)
4× SATA 6Gb/s ports
NVMe RAID 0/1/5/10 (Ryzen 9000)
SATA RAID 0/1/10

Networking
Realtek® 2.5GbE LAN
Wi-Fi 7 (Realtek RTL8922AE, 2×2)
Bluetooth® 5.4

USB Ports
Rear:
1× USB Type-C (DP + data, up to 40Gbps with Ryzen 8000)
2× USB 3.2 Gen2 (Type-A)
5× USB 3.2 Gen1
4× USB 2.0

Front/Internal:
1× USB Type-C (Gen2x2, 20Gbps)
1× USB 3.2 Gen1 header (2 ports)
2× USB 2.0 headers (4 ports)

Audio
Realtek® ALC1220 HD Audio (7.1-channel)
Supports DSD audio, S/PDIF Out

Back Panel I/O
1× HDMI
1× USB Type-C (DP output)
2× USB 3.2 Gen2 Type-A
5× USB 3.2 Gen1
4× USB 2.0
1× Realtek 2.5GbE LAN
2× Wi-Fi antenna connectors
2× Audio jacks + Optical S/PDIF
1× Q-Flash Plus button

Internal I/O
24-pin ATX + 8-pin CPU power
CPU & AIO fan headers, 3× system fan headers
2× M.2 slots, 4× SATA ports
RGB: 3× ARGB Gen2 headers, 1× RGB header
Clear CMOS jumper, reset button

Special Features
Q-Flash & Q-Flash Plus
Smart Backup
Gigabyte Control Center (GCC)
Q-Flash Plus button for BIOS updates
ARGB lighting control

BIOS
256 Mbit Flash, AMI UEFI BIOS

Accessories
Wi-Fi Antenna
SATA Cables
M.2 screws
Quick installation guide

Operating System
Windows 11 64-bit

Form Factor
Micro-ATX (24.4 × 24.4 cm)

Warranty

3 YEARS WARRANTY
